# Tag Archives: QGIS

In Movement data in GIS #16, I presented a new way to deal with trajectory data using GeoPandas and how to load the trajectory GeoDataframes as a QGIS layer. Following up on this initial experiment, I’ve now implemented a first version of an algorithm that performs a spatial analysis on my GeoPandas trajectories.

The first spatial analysis algorithm I’ve implemented is Clip trajectories by extent. Implementing this algorithm revealed a couple of pitfalls:

• To achieve correct results, we need to compute spatial intersections between linear trajectory segments and the extent. Therefore, we need to convert our point GeoDataframe to a line GeoDataframe.
• Based on the spatial intersection, we need to take care of computing the corresponding timestamps of the events when trajectories enter or leave the extent.
• A trajectory can intersect the extent multiple times. Therefore, we cannot simply use the global minimum and maximum timestamp of intersecting segments.
• GeoPandas provides spatial intersection functionality but if the trajectory contains consecutive rows without location change, these will result in zero length lines and those cause an empty intersection result.

So far, the clip result only contains the trajectory id plus a suffix indicating the sequence of the intersection segments for a specific trajectory (because one trajectory can intersect the extent multiple times). The following screenshot shows one highlighted trajectory that intersects the extent three times and the resulting clipped trajectories:

This algorithm together with the basic trajectory from points algorithm is now available in a Processing algorithm provider plugin called Processing Trajectory.

Note: This plugin depends on GeoPandas.

Note for Windows users: GeoPandas is not a standard package that is available in OSGeo4W, so you’ll have to install it manually. (For the necessary steps, see this answer on gis.stackexchange.com)

The implemented tests show how to use the Trajectory class independently of QGIS. So far, I’m only testing the spatial properties though:

```def test_two_intersections_with_same_polygon(self):
polygon = Polygon([(5,-5),(7,-5),(7,12),(5,12),(5,-5)])
data = [{'id':1, 'geometry':Point(0,0), 't':datetime(2018,1,1,12,0,0)},
{'id':1, 'geometry':Point(6,0), 't':datetime(2018,1,1,12,10,0)},
{'id':1, 'geometry':Point(10,0), 't':datetime(2018,1,1,12,15,0)},
{'id':1, 'geometry':Point(10,10), 't':datetime(2018,1,1,12,30,0)},
{'id':1, 'geometry':Point(0,10), 't':datetime(2018,1,1,13,0,0)}]
df = pd.DataFrame(data).set_index('t')
geo_df = GeoDataFrame(df, crs={'init': '31256'})
traj = Trajectory(1, geo_df)
intersections = traj.intersection(polygon)
result = []
for x in intersections:
result.append(x.to_linestring())
expected_result = [LineString([(5,0),(6,0),(7,0)]), LineString([(7,10),(5,10)])]
self.assertEqual(result, expected_result)
```

One issue with implementing the algorithms as QGIS Processing tools in this way is that the tools are independent of one another. That means that each tool has to repeat the expensive step of creating the trajectory objects in memory. I’m not sure this can be solved.

If you follow me on Twitter, you have probably already heard that the ebook of “QGIS Map Design 2nd Edition” has now been published and we are expecting the print version to be up for sale later this month. Gretchen Peterson and I – together with our editor Gary Sherman (yes, that Gary Sherman!) – have been working hard to provide you with tons of new and improved map design workflows and many many completely new maps. By Gretchen’s count, this edition contains 23 new maps, so it’s very hard to pick a favorite!

Like the 1st edition, we provide increasingly advanced recipes in three chapters, each focusing on either layer styling, labeling, or creating print layouts. If I had to pick a favorite, I’d have to go with “Mastering Rotated Maps”, one of the advanced recipes in the print layouts chapter. It looks deceptively simple but it combines a variety of great QGIS features and clever ideas to design a map that provides information on multiple levels of detail. Besides the name inspiring rotated map items, this design combines

• map overviews
• map themes
• a rotated north arrow

all in one:

“QGIS Map Design 2nd Edition” provides how-to instructions, as well as data and project files for each recipe. So you can jump right into it and work with the provided materials or apply the techniques to your own data.

The ebook is available at LocatePress.

In Movement data in GIS #2: visualization I mentioned that it should be possible to label trajectory segments without having to break the original trajectory feature. While it’s not a straightforward process, it is indeed possible to create timestamp labels at desired intervals:

The main point here is that we cannot use regular labels because there would be only one label for the whole trajectory feature. Instead, we are using a marker line with a font marker:

By default, font markers only display one character from a given font but by using expressions we can make it display longer text, including datetime strings:

If you want to have a label at every node of the trajectory, the expression looks like this:

```format_date(
to_datetime('1970-01-01T00:00:00Z')+to_interval(
m(start_point(geometry_n(
segments_to_lines( \$geometry ),
@geometry_part_num)
))||' seconds'
),
'HH:mm:ss'
)
```

You probably remember those parts of the expression that extract the m value from previous posts. Note that – compared to 2016 – it is now necessary to add the segments_to_lines() function.

The m value (which stores time as seconds since Unix epoch) is then converted to datetime and finally formatted to only show time. Of course you can edit the datetime format string to also include the date.

If we only want a label every 30 seconds, we can add a case statement around that:

```CASE WHEN
m(start_point(geometry_n(
segments_to_lines( \$geometry ),
@geometry_part_num)
)) % 30 = 0
THEN
format_date(
to_datetime('1970-01-01T00:00:00Z')+to_interval(
m(start_point(geometry_n(
segments_to_lines( \$geometry ),
@geometry_part_num)
))||' seconds'
),
'HH:mm:ss'
)
END
```

This works well if the trajectory sampling interval is fairly regular. This is not always the case and that means that the above case statement wouldn’t find many nodes with a timestamp that ends in :30 or :00. In such a case, we could resort to labeling nodes based on their order in the linestring:

```CASE WHEN
@geometry_part_num  % 30 = 0
THEN
...
```

Thanks a lot to @JuergenEFischer for providing a solution for converting seconds since Unix epoch to datetime without a custom function!

Note that expressions using @geometry_part_num currently suffer from the following issue: Combination of segments_to_lines(\$geometry) and @geometry_part_num gives wrong segment numbers

This post is part of a series. Read more about movement data in GIS.

Remember the good old times when all parameters in Processing were mandatory?

Inputs and outputs are ﬁxed, and optional parameters or outputs are not supported. [Graser & Olaya, 2015]

Since QGIS 2.14, this is no longer the case. Scripts, as well as models, can now have optional parameters. Here is how for QGIS 3:

When defining a Processing script parameter, the parameter’s constructor takes a boolean flag indicating whether the parameter should be optional. It’s false by default:

```class qgis.core.QgsProcessingParameterNumber(
name: str, description: str = '',
type: QgsProcessingParameterNumber.Type = QgsProcessingParameterNumber.Integer,
defaultValue: Any = None,
optional: bool = False,
minValue: float = -DBL_MAX+1, maxValue: float = DBL_MAX)
```

One standard tool that uses optional parameters is Add autoincremental field:

From Python, this algorithm can be called with or without the optional parameters:

When building a model, an optional input can be assigned to the optional parameter. To create an optional input, make sure to deactivate the mandatory checkbox at the bottom of the input parameter definition:

Then this optional input can be used in an algorithm. For example, here the numerical input optional_value is passed to the Start values at parameter:

You can get access to all available inputs by clicking the … button next to the Start values at field. In this example, I have access to values of the input layer as well as  the optional value:

Once this is set up, this is how it looks when the model is run:

You can see that the optional value is indeed Not set.

## References

Graser, A., & Olaya, V. (2015). Processing: A Python Framework for the Seamless Integration of Geoprocessing Tools in QGIS. ISPRS Int. J. Geo-Inf. 2015, 4, 2219-2245. doi:10.3390/ijgi4042219.

Processing has been overhauled significantly for QGIS 3.0. Besides speed-ups, one of the most obvious changes is the way to write Processing scripts. Instead of the old Processing-specific syntax, Processing scripts for QGIS3 are purely pythonic implementations of QgsProcessingAlgorithm.

Here’s a template that you can use to develop your own algorithms:

```from qgis.PyQt.QtCore import QCoreApplication, QVariant
from qgis.core import (QgsField, QgsFeature, QgsFeatureSink, QgsFeatureRequest, QgsProcessing, QgsProcessingAlgorithm, QgsProcessingParameterFeatureSource, QgsProcessingParameterFeatureSink)

class ExAlgo(QgsProcessingAlgorithm):
INPUT = 'INPUT'
OUTPUT = 'OUTPUT'

def __init__(self):
super().__init__()

def name(self):
return "exalgo"

def tr(self, text):
return QCoreApplication.translate("exalgo", text)

def displayName(self):
return self.tr("Example script")

def group(self):
return self.tr("Examples")

def groupId(self):
return "examples"

def shortHelpString(self):
return self.tr("Example script without logic")

def helpUrl(self):
return "https://qgis.org"

def createInstance(self):
return type(self)()

def initAlgorithm(self, config=None):
self.INPUT,
self.tr("Input layer"),
[QgsProcessing.TypeVectorAnyGeometry]))
self.OUTPUT,
self.tr("Output layer"),
QgsProcessing.TypeVectorAnyGeometry))

def processAlgorithm(self, parameters, context, feedback):
source = self.parameterAsSource(parameters, self.INPUT, context)
(sink, dest_id) = self.parameterAsSink(parameters, self.OUTPUT, context,
source.fields(), source.wkbType(), source.sourceCrs())

features = source.getFeatures(QgsFeatureRequest())
for feat in features:
out_feat = QgsFeature()
out_feat.setGeometry(feat.geometry())
out_feat.setAttributes(feat.attributes())

return {self.OUTPUT: dest_id}
```

This script just copies the features of the input layer to the output layer without any modifications. Add your logic to the processAlgorithm() function to get started.

Use Create New Script from the Toolbox toolbar:

Paste the example script:

Once saved, the script will show up in the Processing toolbox:

Joining polygon attributes to points based on their location is a very common GIS task. In QGIS 2, QGIS’ own implementation of “Join attributes by location” was much slower than SAGA’s “Add polygon attributes to points”. Thus, installations without SAGA were out of good options.

Luckily this issue (and many more) has been fixed by the rewrite of many geoprocessing algorithms for QGIS 3! Let’s revisit the comparison:

I’m using publicly available datasets from Naturalearth: The small scale populated places (243 points) and the large scale countries (255 polygons with many nodes). Turns out that QGIS 3’s built-in tool takes a little less than two seconds while the SAGA Processing tool requires a litte less than six seconds:

Like in the previous comparison, times were measured using the Python Console:

In both tools, only the countries’ SOVEREIGNT attribute is joined to the point attribute table:

```import processing
import datetime
t0 = datetime.datetime.now()
print("QGIS Join attributes by location ...")
"qgis:joinattributesbylocation",
{'INPUT':'E:/Geodata/NaturalEarth/vector_v4/natural_earth_vector/110m_cultural/ne_110m_populated_places.shp',
'PREDICATE':[5],'JOIN_FIELDS':['SOVEREIGNT'],

t1 = datetime.datetime.now()
print("Runtime: "+str(t1-t0))

print("SAGA Add polygon attributers to points ...")
{'INPUT':'E:/Geodata/NaturalEarth/vector_v4/natural_earth_vector/110m_cultural/ne_110m_populated_places.shp',
'FIELDS':'SOVEREIGNT','OUTPUT':'C:/Users/anita/AppData/Local/Temp/processing_8b1bbde78de5490285dd530e115cca52/099660d88bf14c54a853cc230e388e55/OUTPUT.shp'})

t2 = datetime.datetime.now()
print("Runtime: "+str(t2-t1))
```

It is worth noting that it takes longer if more attributes are to be joined to the point layer attribute table. For example, if the JOIN_FIELDS parameter is empty:

`'JOIN_FIELDS':[]`

`'JOIN_FIELDS':['SOVEREIGNT']`

then the the Join attributes by location takes almost 16 seconds. (The country layer contains 71 attributes after all.)

(The SAGA tool currently allows only joining one attribute at a time.)

The release of 3.0 is really close now. If you want to know what’s new or are just looking for interesting ways to pass the time until the packages land, check out the following QGIS3 resources.

For users

For more recordings from the developer meeting in Madeira check my Youtube playlist.

For developers

TimeManager 2.5 is quite likely going to be the final TimeManager release for the QGIS 2 series. It comes with a couple of bug fixes and enhancements:

• Fixed #245: updated help.htm
• Fixed #240: now hiding unmanageable WFS layers
• Fixed #220: fixed issues with label size
• Fixed #194: now exposing additional functions: animation_time_frame_size, animation_time_frame_type, animation_start_datetime, animation_end_datetime

Besides updating the help, I also decided to display it more prominently in the settings dialog (similarly to how the help is displayed in the field calculator or in Processing):

So far, I haven’t started porting to QGIS 3 yet. If you are interested in TimeManager and want to help, please get in touch.

On this note, let me leave you with a couple of animation inspirations from the Twitterverse:

I’ll start with some tech talk first. Feel free to jump to the usage example further down if you are here for the edge bundling plugin.

As you certainly know, QGIS 3 brings a lot of improvements and under-the-hood changes. One of those changes affects all Python scripts. They need to be updated to Python 3 and the new PyQGIS API. (See the official migration guide for details.)

To get ready for the big 3.0 release, I’ve started porting my Processing tools. The edge bundling script is my first candidate for porting to QGIS 3. I also wanted to use this opportunity to “upgrade” from a simple script to a plugin that integrates into Processing.

I used Alexander Bruy’s “prepair for Processing” plugin as a template but you can also find an example template in your Processing folder. (On my system, it is located in C:\OSGeo4W64\apps\qgis-dev\python\plugins\processing\algs\exampleprovider.)

Since I didn’t want to miss the advantages of a good IDE, I set up PyCharm as described by Heikki Vesanto. This will give you code completion for Python 3 and PyQGIS which is very helpful for refactoring and porting. (I also tried Eclipse with PyDev but if you don’t have a favorite IDE yet, I find PyCharm easier to install and configure.)

My PyCharm startup script qgis3_pycharm.bat is a copy of C:\OSGeo4W64\bin\python-qgis-dev.bat with the last line altered to start PyCharm:

```@echo off
call "%~dp0\o4w_env.bat"
call qt5_env.bat
call py3_env.bat
@echo off<span data-mce-type="bookmark" style="display: inline-block; width: 0px; overflow: hidden; line-height: 0;" class="mce_SELRES_start"></span>
path %OSGEO4W_ROOT%\apps\qgis-dev\bin;%PATH%
set QGIS_PREFIX_PATH=%OSGEO4W_ROOT:\=/%/apps/qgis-dev
set GDAL_FILENAME_IS_UTF8=YES
rem Set VSI cache to be used as buffer, see #6448
set VSI_CACHE=TRUE
set VSI_CACHE_SIZE=1000000
set QT_PLUGIN_PATH=%OSGEO4W_ROOT%\apps\qgis-dev\qtplugins;%OSGEO4W_ROOT%\apps\qt5\plugins
set PYTHONPATH=%OSGEO4W_ROOT%\apps\qgis-dev\python;%PYTHONPATH%
start /d "C:\Program Files\JetBrains\PyCharm\bin\" pycharm64.exe
```

In PyCharm File | Settings, I configured the OSGeo4W Python 3.6 interpreter and added qgis-dev and the plugin folder to its path:

With this setup done, we can go back to the code.

I first resolved all occurrences of import * in my script to follow good coding practices. For example:

```from qgis.core import *
```

became

```from qgis.core import QgsFeature, QgsPoint, QgsVector, QgsGeometry, QgsField, QGis<span data-mce-type="bookmark" style="display: inline-block; width: 0px; overflow: hidden; line-height: 0;" class="mce_SELRES_start"></span>
```

in this PR.

I didn’t even run the 2to3 script that is provided to make porting from Python 2 to Python 3 easier. Since the edge bundling code is mostly Numpy, there were almost no changes necessary. The only head scratching moment was when Numpy refused to add a map() return value to an array. So (with the help of Stackoverflow of course) I added a work around to convert the map() return value to an array as well:

```flocal_x = map(forcecalcx, subtr_x, subtr_y, distance)
electrostaticforces_x[e_idx, :] += np.array(list(flocal_x))
```

The biggest change related to Processing is that the VectorWriter has been replaced by a QgsFeatureSink. It’s defined as a parameter of the edgebundling QgsProcessingAlgorithm:

```self.addParameter(QgsProcessingParameterFeatureSink(
self.OUTPUT,
self.tr("Bundled edges"),
QgsProcessing.TypeVectorLine)
)
```

And when the algorithm is run, the sink is filled with the output features:

```(sink, dest_id) = self.parameterAsSink(
parameters, self.OUTPUT, context,
source.fields(), source.wkbType(), source.sourceCrs()
)

# code that creates features

```

The ported plugin is available on Github.

The edge bundling plugin in action

I haven’t uploaded the plugin to the official plugin repository yet, but you can already download if from Github and give it a try:

For this example, I’m using taxi pick-up and drop-off data provided by the NYC Taxi & Limousine Commission. I downloaded the January 2017 green taxi data and extracted all trips for the 1st of January. Then I created origin-destination (OD) lines using the QGIS virtual layer feature:

To get an interesting subset of the data, I extracted only those OD flows that cross the East River and have a count of at least 5 taxis:

Now the data is ready for bundling.

If you have installed the edge bundling plugin, the force-directed edge bundling algorithm should be available in the Processing toolbox. The UI of the edge bundling algorithm looks pretty much the same as it did for the QGIS 2 Processing script:

Since this is a small dataset with only 148 OD flows, the edge bundling processes is pretty quick and we can explore the results:

Beyond this core edge bundling algorithm, the repository also contains two more scripts that still need to be ported. They include dependencies on sklearn, so it will be interesting to see how straightforward it is to convert them.

QGIS 3 has a new feature: reports! In short, reports are the good old Altas feature on steroids.

Let’s have a look at an example project:

To start a report, go to Project | New report. The report window is quite similar to what we’ve come to expect from Print Composer (now called Layouts). The most striking difference is the report panel at the left side of the screen.

When a new report is created, the center of the report window is empty. To get started, we need to select the report entry in the panel on the left. By selecting the report entry, we get access to the Include report header and Include report footer checkboxes. For example, pressing the Edit button next to the Include report header option makes it possible to design the front page (or pages) of the report:

Similarly, pressing Edit next to the Include report footer option enables us to design the final pages of our report.

Now for the content! We can populate our report with content by clicking on the plus button to add a report section or a “field group”. A field group is basically an Atlas. For example, here I’ve added a field group that creates one page for each country in the Natural Earth countries layer that I have loaded in my project:

Note that in the right panel you can see that the Controlled by report option is activated for the map item. (This is equivalent to a basic Atlas setup in QGIS 2.x.)

With this setup, we are ready to export our report. Report | Export Report as PDF creates a 257 page document:

As configured, the pages are ordered by country name. This way, for example, Australia ends up on page 17.

Of course, it’s possible to add more details to the individual pages. In this example, I’ve added an overview map in Robinson projection (to illustrate again that it is now possible to mix different CRS on a map).

Happy QGIS mapping!
